PRO2092A-08: 4K*2K HDMI Splitter, 1 In 8 Outs

4K*2K HDMI Splitter, 1 In 8 Outs. This is an HDMI splitter with eight outputs. It distributes the input of the HDMI signal into the eight identical outputs simultaneously. It supports full 3D format and 4Kx2K. Its video amplifier bandwidth can be up to 3

Promotion:

For Large Quantity Orders, Feel Free to Contact us at Anytime.

Quantity:

Description

Additional information

This is an HDMI splitter with eight outputs. It distributes the input of the HDMI signal into the eight identical outputs simultaneously. It supports full 3D format and 4Kx2K. Its video amplifier bandwidth can be up to 3.2Gpbs/320MHz.


Features
Support high resolution up to 3840X2160/30HZ
Support 3D video format
Support highest rate of 3.2 G and TMDS clock can be up to 320 MHz
Support 8/10/12 bit deep color
Support AWG26 HDMI standard cable (Input 15M, Output 25M)
4K Resolution (Input 12M, Output 15M)
5V/1A power adapter
Specifications

HDMI resolution                               3840*2160/30Hz
Support video format                       8/10/12bit deep color
Support audio format                       DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
Max bandwidth                                 320MHz
Max band rate                                   3.2Gbps
Max working current                        1.58 A
Power adapter format                      Input AC (50HZ, 60HZ) 100V-240V
                                                             Output: DC12V/2A
Operating Temperature range       (-15 to +55℃)
Dimension (L x W x H)                     276x136x24 (mm)
Weight                                                660g
